Medical devices are one area where EMC covers both safety and reliability, and thus the system design guidelines require multiple approaches not seen in other commercial products. Furthermore, there are more numerous and more stringent EMC standards imposed on medical devices due to their requirement for perpetual uptime and patient safety.
The intersection between user safety and reliability always leads to more specialized PCB design approaches that are not always seen in other commercial products. Before starting your next medical device PCB layout, make sure the specific EMC tests and emissions/immunity targets are well-understood. This guide will present some PCB layout practices that can aid EMC compliance in medical devices.
Key Takeaways from this article
- Medical device EMC standards address both safety and reliability — unlike typical commercial products
- IEC 60601-1-2, Edition 4.1 is the primary EMC standard for medical electrical equipment
- FDA regulations explicitly reference EMC compliance for patient safety
- PCB design decisions in sensors, grounding, and flexible circuits directly impact EMC performance
- Early-stage EMC design prevents costly late-stage failures and board respins
Two critical factors drive stringent EMC requirements:
- Patient safety: Devices must not expose patients to harmful emissions or interference
- Perpetual uptime: Medical equipment requires uninterrupted, reliable operation
Due to this interplay between EMC and patient safety, EMC requirements are explicitly referenced in FDA regulations for electronic medical devices.
Before starting your next medical device PCB layout, ensure the specific EMC tests and emissions/immunity targets are well-understood.
Medical Device EMC Standards Overview
Regulators often wrap these with submission expectations and labeling: FDA’s EMC guidance applies broadly (including IVD), and if you have radios you also inherit “wireless-specific” expectations (i.e., FDA wireless guidance).
Primary Standards by Product Type:
| Product Type | Primary EMC Standard | Purpose |
|---|---|---|
| Medical Electrical (ME) Equipment | IEC 60601-1-2 (collateral to IEC 60601-1) | Device maintains basic safety and essential performance under EM disturbances; limits emissions |
| In-Vitro Diagnostics (IVD) | IEC 61326 family, especially IEC 61326-2-6 | Basic safety + essential performance for IVD equipment and environments |
| Implantable Devices | ISO 14708 family |
Device-specific EMC immunity for implantable therapy/sensing + lead system interactions |
Align Your Medical Device With Industry Standards:
Before starting this is some level design or PCB layout for a medical device, the relevant EMC standards should be known and understood. EMC compliance is not just a requirement for medical products to be legally released to markets around the world, it is also part of patient safety. Due to interplay between EMC and patient safety, EMC requirements are explicitly referenced in the FDA regulations for electronic medical devices.
The main set of industry EMC standards for medical devices are:
IEC 60601-1-2, Edition 4.1
This is the primary EMC collateral standard for medical electrical equipment and systems. Key coverage includes:
- Emissions limits — Controls unintentional electromagnetic interference
- Immunity test requirements — Ensures devices function under EM disturbances
- Environment-based test levels — Professional healthcare, home healthcare, and special environments
Source: IEC 60601-1-2:2014+AMD1:2020
IEC 61000-4 Family
Specifies immunity testing methods referenced by IEC 60601-1-2, including:
- ESD testing
- Radiated and conducted emissions
- Voltage dips, surges, and interruptions
IEC 61326 Family
Frequently cited by regulators for in-vitro diagnostics (IVD) equipment. FDA's recognized consensus standards include IVD-focused 61326 parts.
ISO 14708 Family
Specifies requirements for implantable devices, including active implantable electronic devices. Device-specific standards supplement the base ISO 14708 standard — for example, ISO 14117 covers cardiovascular implants.
Source: ISO 14117 — Cardiovascular Implants
EMC Design Practices for Medical Device PCBs
The following examples address common EMC design challenges in medical devices.
Example 1: Sensors, Noise, and Grounding
Medical devices frequently contain sensors that interface directly with patients or monitor critical parameters. These sensors are often highly susceptible to noise, with low signal-to-noise ratios (SNR).
PCB layout practices for sensor EMC:
- Do not split grounds unless required for patient safety
- Never route traces over ground splits — this creates return path problems
- Use isolated ADCs or optical coupling for analog-to-digital conversion
- Consider digital isolators for logic circuits
- Separate analog and digital sections as much as physically possible
Interference most often comes from failure to understand return paths, leading to inaccurate sensor readings, emissions, or device failure.
Example 2: Patient Safety and Reliability
Patient safety focuses on two primary EMC issues:
- Patient exposure — Leakage currents, radio emissions, or ESD risks
- Equipment interference — One device disrupting another's operation
Design approach:
Treat every port on the device as a potential source or sink of currents and radiated emissions.
Key practices:
- Chassis grounding for connector shrouds
- Cable shield grounding where necessary
- Low-leakage Y-type capacitors across ground domains for galvanic isolation
Excessive leakage current can interact with patients (as ESD), creating safety risks. Multiple diagnostic devices may interfere with each other, causing functional failures.
Example 3: Flexible and Wearable Designs
Wearable medical devices often use flexible or rigid-flex designs with direct body contact for diagnostics like temperature monitoring or pulse oximetry.
Challenge: Flexible PCB sections typically use hatched ground planes (not solid) for mechanical flexibility. Hatched ground planes allow high-frequency radiation to pass through openings.
Immunity solutions:
- Use striplines with hatched planes for partial shielding
- Convert analog interfaces to differential signaling and route accordingly
- Design filter circuits on analog interfaces
- Place solid ground rails below specific critical interconnects
These approaches balance EMC performance with the flexibility requirements of wearable devices.
Frequently Asked Questions
What is the current edition of IEC 60601-1-2?
Edition 4.1 (IEC 60601-1-2:2014+AMD1:2020) is the current edition, published in September 2020. This consolidated version includes the fourth edition and Amendment 1.
How does medical device EMC testing differ from commercial products?
Medical device EMC testing requires that basic safety and essential performance be maintained during immunity tests — not just that the device survives. The device must continue performing its intended medical function.
Why are medical device EMC requirements more stringent?
Medical devices must address both patient safety (exposure to emissions, leakage currents) and operational reliability (perpetual uptime, interference with other equipment). This dual requirement creates more numerous and stricter standards.
What is "essential performance" in medical device EMC?
Essential performance refers to the device functions necessary for safety. During EMC testing, these functions must continue operating within specification. For example, an infusion pump must maintain accurate flow rates during immunity tests.
